B-SIDE LED

Download PDF

LIGHT TECHNOLOGY

LED

System Power:

2W / 2.4W / 3W / 4.8W

Colour Temperature:

4000K

Luminous flux:

up to 171Lm

Colour rendering index (CRI):

>80

Luminaire Efficiency:

up to 57.5Lm/W

Lighting Distribution:

Symmetric

Weight:

1.45Kg / 2.79Kg / 4.2Kg

Protection rating. Class:

IP65 , I

Color:

Grey

Dimensions:

Ø:160 x H:135mm / Ø:160 x H:450mm / Ø:160 x H:850mm

System Power: 2W / 2.4W / 3W / 4.8W

Colour Temperature: 4000K

Luminous flux: up to 171Lm

Colour rendering index (CRI): >80

Luminaire Efficiency: up to 57.5Lm/W

Lighting Distribution: Symmetric

Weight: 1.45Kg / 2.79Kg / 4.2Kg

Protection rating. Class: IP65 , I

Color: Grey

Dimensions: Ø:160 x H:135mm / Ø:160 x H:450mm / Ø:160 x H:850mm

DETAILS

APPLICATION
Outdoor Lighting

MANUFACTURER

COUNTRY OF ORIGIN
SPAIN

B-SIDE LED

Bollard model B-SIDE LED 850 250 NW GR., LAMP brand. Made of texturised grey lacquered aluminium extrusion and injection, and translucent polycarbonate diffuser. 850mm in height. Its base has an anti-corrosion electro coating treatment. Model for HI-POWER LED, with neutral white colour temperature and control gear included. IP65, IK10 protection rating. Insulation class I.
