DOMA 195 LED

Download PDF

LIGHT TECHNOLOGY

LED

System Power:

16W

Colour Temperature:

4000K

Luminous FLux:

1939Lm

Colour Rendering Index (CRI):

>80

Luminaire Efficiency:

124Lm/W

Weight:

0.83Kg

Protection rating. Class:

IP20 , III

Dimensions:

Ø:246 x H:113mm

System Power: 16W

Colour Temperature: 4000K

Luminous FLux: 1939Lm

Colour Rendering Index (CRI): >80

Luminaire Efficiency: 124Lm/W

Weight: 0.83Kg

Protection rating. Class: IP20 , III

Dimensions: Ø:246 x H:113mm

DETAILS

APPLICATION
Office Lighting
Retail Lighting

MANUFACTURER

COUNTRY OF ORIGIN

DOMA 195 LED

Recessed downlight. Housing made of sheet steel with cover ring made of diecast aluminium painted in RAL 9016 traffic white, with driver wired ready for operation. With mounting springs for installation without tools, suitable for ceiling thickness of 10 mm-25 mm. Housing colour white; Direct wide-beam light distribution using specular individually anodised reflector made of ultra-pure aluminium, for workstations, 65° < 1000 cd/m² with omnidirectional glare suppression according to current DIN-EN 12464-1 standard; External driver with luminaire wired ready for operation. Electrical connection via 3-pole connection terminal with plug-in contacts.
